10,5cm lFH Ammunition

Above:  Illumination projectile (left) and the long pattern high explosive projectile l.F.H. Gr. (right) for the 10,5cm lFH 1898/09, 10,5cm lFH 1916, and the 10,5cm lFH 1916 Kp.  The fuze on the illumination projectile is a very detailed reproduction of the Lg. Zdr. S/22

(Left) reproduction of the Lg. Zdr. S/22 fuze (Middle) L.H.Z. 17 (Right) H.Z. 14

Below: The 10,5cm HE projectile along with the wicker basket to hold two projectiles on the left and right compartments and shell cases in the middle compartment

Below: Front view of the 10,5cm projectile and shell case wicker basket

Below: Top view of the 10,5cm projectile and shell case wicker basket

Below: Side view of the 10,5cm projectile and shell case wicker basket

Below: Bottom view of the 10,5cm projectile and shell case wicker basket

Below: View of the 10,5cm projectile and shell case wicker basket leather tab marked AWS and dated 1912

Below: Front view of the 10,5cm projectile and shell case wicker basket

Below: View of the edge of the 10,5cm projectile and shell case wicker basket. You can see the divided compartment center for the shell cases in this view
